Electric Off Road Vehicle ROCK

Product Overview

The ROCK Electric ATV Vehicle is a high-performance electric off road vehicle designed for agriculture, industrial applications, and extreme terrain operations. Built with a focus on torque strength, structural durability, and zero-emission mobility, it delivers stable and efficient performance across farms, ranches, forests, construction zones, and rugged outdoor environments.

Unlike conventional fuel-powered ATVs, this model integrates advanced electric drivetrain technology with intelligent control systems, ensuring smooth power delivery, lower maintenance requirements, and significantly improved operational efficiency. It is engineered for users who require consistent off-road capability combined with sustainable energy performance.

High-Performance Electric Power System

At the core of the ROCK electric off road vehicle is a high-torque electric motor system designed for demanding workloads and continuous field operation. The system prioritizes torque output over speed optimization, making it ideal for towing, climbing, and load-bearing tasks.

Key performance specifications include:

• Maximum speed: up to 70 km/h

• Rated power: 12 kW

• Peak power output: 17 kW (22.8 HP)

• Maximum torque: 136 N·m

• Wheel torque output: 1923 N·m

• Driving range: up to 120 km per charge

This power configuration ensures strong acceleration under load and stable performance on uneven terrain such as mud, gravel, sand, and steep inclines. The instant torque response of the electric motor provides superior control compared to traditional combustion engines, especially in low-speed agricultural and industrial applications.

Advanced Battery and Energy Architecture

The ROCK electric off road vehicle is equipped with a high-capacity lithium battery system engineered for durability, efficiency, and long service life. Users can choose between ternary lithium or LFP battery configurations depending on operational requirements.

Battery specifications:

• Voltage system: 144V

• Capacity options: 110Ah / 70Ah

• Battery types: Ternary lithium / Lithium Iron Phosphate (LFP)

The energy system is designed to deliver stable voltage output even under continuous load conditions. Intelligent battery management ensures optimized energy distribution, temperature control, and extended cycle life.

This makes the vehicle suitable for long-duration field operations where reliability and endurance are essential.

Heavy-Duty Frame and Off-Road Capability

Structural integrity is a key feature of this electric off road vehicle. The chassis is built with reinforced materials designed to withstand heavy-duty agricultural and industrial usage.

Structural performance highlights:

• Payload capacity: 255 kg

• Vehicle weight: 505 kg

• Ground clearance: 300 mm

• Wheelbase: 1460 mm

• Maximum climbing angle: 40°

The reinforced frame ensures stability under heavy loads, while the high ground clearance allows the vehicle to navigate rocks, deep ruts, and uneven terrain with ease. The suspension system is engineered to absorb shocks efficiently, reducing operator fatigue during long working hours.

Intelligent 2WD and 4WD Drive System

One of the most practical features of the ROCK electric off road vehicle is its intelligent drivetrain system, which allows seamless switching between 2WD and 4WD modes.

• 2WD Mode:
  Optimized for energy efficiency, suitable for flat terrain, light transport tasks, and extended driving range.

• 4WD Mode:
  Provides maximum traction and torque distribution for off-road conditions, steep slopes, and heavy-load operations.

This adaptive system ensures that users can balance performance and energy consumption based on real-time working conditions, improving overall operational flexibility.

Multi-Scenario Application Capability

The ROCK electric off road vehicle is designed for both professional and recreational use, offering wide adaptability across multiple industries and environments.

Primary application areas include:

• Agricultural farming and crop transport

• Livestock feeding and ranch management

• Forestry operations and maintenance work

• Industrial site transportation

• Security patrol and inspection tasks

• Emergency rescue support

• Off-road exploration and outdoor logistics

• Camping and recreational travel

Its compact design and strong torque output make it suitable for environments where traditional vehicles cannot operate efficiently.

Customization and Modular Accessories

To meet diverse operational requirements, the vehicle supports a wide range of modular accessories and upgrades.

Available options include:

• Electric winch system

• Underbody skid plates for protection

• Rear tow hook system

• Front axle protection guards

• Cargo storage boxes

• Protective safety railings

• Portable power inverter kits

• Enhanced shock absorption systems

• Visibility flag mounting kits

These modular configurations allow users to customize the vehicle for specific tasks such as farming, towing, rescue operations, or industrial transport.

Ergonomic Design and Dimensions

The ROCK electric off road vehicle is engineered for both comfort and functionality, supporting two-person seating and long-duration operation.

Design specifications:

• Overall dimensions: 2245 × 1278 × 1400 mm

• Seat height: 900 mm

• Seating capacity: 2 persons

The ergonomic seating position ensures stability during off-road movement while reducing operator fatigue. The compact frame allows easy maneuverability in narrow pathways, orchards, and confined workspaces.

Color Options and Durability Finish

To suit different operational environments, the vehicle is available in multiple outdoor-ready color finishes:

• Forest Green

• Desert Yellow

• Star Grey

Each finish is designed with UV-resistant and wear-resistant coatings to ensure long-term durability under harsh environmental conditions.

Operational Advantages in Real-World Use

In practical applications, the ROCK electric off road vehicle provides several key advantages over traditional utility ATVs:

• Instant torque delivery for improved load handling

• Lower maintenance requirements due to simplified electric drivetrain

• Reduced noise for livestock and residential farm environments

• Lower operational costs compared to fuel-powered models

• Stable performance across varied terrain conditions

• Flexible 2WD/4WD switching for energy optimization

These benefits make it particularly valuable for users who require consistent daily operation under demanding conditions.

Conclusion

The ROCK Electric ATV Vehicle represents a new generation of electric off road vehicle technology designed for modern agriculture and industrial mobility. With high torque performance, intelligent drivetrain control, durable structural engineering, and zero-emission operation, it delivers a balanced combination of power, efficiency, and adaptability.

Whether used for farming, forestry, logistics, or outdoor exploration, this electric ATV provides a reliable and sustainable mobility solution that meets the demands of today’s evolving work environments.
