This ELP 5MP USB Camera Module with 2pcs Microphone boasts a advanced 1/2.8″ CMOS IMX335 image sensor
* Sensor: With industrial grade high quality 1/2.8" CMOS IMX335 Sensor;
* With 2pcs Microphone
* Resolution: Full HD 2592*1944P Color USB Camera Module;
* High Speed: High frame rate, MJPEG：2592×1944 @ 30fps MJPEG / 1920×1080 @ 30fps MJPEG, etc.
* Megapixel Lens: High Quality lenses with no distortion lens
* Mini Size: Small outline mini size 38*38mm for embedded application;
* High Quality Image: Super Image reality, real color reproduction, without interpolation;
* UVC Support: Free Driver , Plug and Play, easily used on different systems;
* Support Systems: Windows, Linux, Android, Mac OS, Ubuntu, Raspberry Pi…;
* OTG Support: can be used on Android smartphone, recommended app "USB Camera".
* Wide Application: Wildly used for Car and ship control, electronic equipment, oil field equipment, industrial equipment, remote site monitoring,
environmental monitoring, etc
|
Model |
ELP-USB500W08-L185 (HFOV 200 degree) Optional Model: ELP-USB500W08-L170 (HFOV 138 degree) |
|
Sensor |
CMOS IMX335 |
|
Sensor Size |
1/2.8inch |
|
Pixel Size |
2.0um |
|
Image Area |
5.8mm x 4.75mm |
|
Max. Resolution |
2592(H) X 1944(V) 2Megapixel |
|
Default Resolution |
2592(H) X1944(V) |
|
Compression Format |
MJPEG/ YUY2(YUYV) |
|
Resolution & Frame Rate |
2592×1944 MJPEG 30fps/ YUY2 1fps 2048×1536 MJPEG 30fps/ YUY2 3fps 1920×1080 MJPEG 30fps/ YUY2 3fps 1600×1200 MJPEG 30fps/ YUY2 5fps 1280×960 MJPEG 30fps/ YUY2 5fps 1280×720 MJPEG 30fps / YUY2 5fps 1024 x 768 MJPEG 30fps/ YUY2 5fps 800 x 600 MJPEG 30fps / YUY2 20fps 640×480 MJPEG 30fps / YUY2 30fps 320×240 MJPEG 30fps / YUY2 30fps |
|
Min Illumination |
0.2Lux |
|
Shutter Type |
Rolling Shutter |
|
Connecting Port Type |
USB2.0 High Speed |
|
Free Drive Protocol |
USB Video Class (UVC) |
|
AEC |
Support |
|
AWB |
Support |
|
AGC |
